AA Performance Products VW Piston & Cylinder Set, 77 x 64mm, 40hp, Cast, VW7700T40

AA Performance Products VW Piston & Cylinder Set, 77 x 64mm, 40hp, Cast

AA Performance Products offers a high-quality piston and cylinder set, also known as pistons and liners, designed specifically for the Volkswagen Type-1 engine. This set features hypereutectic pistons paired with cast iron cylinders (or liners) that provide exceptional performance. The hypereutectic cast pistons are stronger than common cast aluminum pistons, making them suitable for stock replacement and certain performance engine combinations. However, it is important to note that these hypereutectic pistons are not recommended for high horsepower naturally aspirated, nitrous, supercharged, or turbo applications.

Specifications:

Piston Style: Flat Top
Material: Cast Hypereutectic
Bore: 77mm
Stroke: 64mm
Compression: 38.05mm
Wrist Pin Dia: 20mm
Cylinder Head Bore: 90mm
Engine Case Bore: 87mm

Piston & Cylinder Set Includes:

• (4) - Cast Iron Cylinders/Liners
• (4) - Cast Hypereutectic Pistons
• (4) - Piston Ring Sets
• (4) - Wrist Pins
• (8) - Wrist Pin Clips

AA Performance Products Piston & Cylinder Set, 77 x 64mm, 40hp, Cast, Sold as Set
